HandlingLinearScales3.CautionsregardingmountingtheSTscale(excludingtheABSST700)MainscaletutoyoMiDirectionfromwhichtheMitutoyologocanbereadDetectorheadG0.01G0.01GindicatesthemachineguidewayisthereferencesurfaceMainscaleRemovethescaleprotectivetape•Mountthemainscalesothatthedetectorheadisfacingthescalefrontsurface(thesurfaceonwhichrainbowcolorsarevisiblewhenlightstrikesthesurfaceatanangle).(ModelsthathavetheMitutoyologoonthemainscalearemountedcorrectlywhenthelogocanbereadfromthedetectorheadside.)•Ambientlightenteringfromthebackofthemainscalewillcauseincorrectoperation,sothescalemountingdesignmustensurethatambientlightdoesnotenter.•Useatoolsuchasalevertypeindicatorordialgagetomovetheheadbracketandthescalemountingrelativelyinordertocheckwhetherthescalemountingsurfacehasbeenpreparedasshowninthemountingdiagram.•Useflexibleadhesivewithadhesivetypescales.WerecommendthatyouuseKE441TmanufacturedbyShin-EtsuChemicalCo,Ltd.•RemovetheprotectivetapeattachedtotheglassscaleandMitutoyoメインスケールdetectorheadwhenyouinstallthedevice.Mitutoyoロゴが見える方向検出ヘッド8-51
| <
|
> |
>>
